[개발환경] Spring + Maven + MyBatis + PostgreSQL Upgrade 본문

Spring Framework

[개발환경] Spring + Maven + MyBatis + PostgreSQL Upgrade

헤르메스의날개 2023. 5. 23. 23:54
728x90

 이전 개발 환경 셋팅한 내용이 좀 오래된 내용이더군요.

https://hermeslog.tistory.com/633



[개발환경] Spring + Maven + MyBatis + PostgreSQL

개발환경 Eclipse Java EE IDE for Web Developers ( Eclipse IDE Neon 3 Packages x64 ) Spring 3.2.14 Maven 3.8.6 MyBastis 3.1.1 PostgreSQL 14.1 Tomcat 8.5.81 JDK 1.8.0_202 DBCP + MyBatis 를 이용한 PostgreSQL 접속 방법 context-common.xml context-da

hermeslog.tistory.com

그래서 Upgrade를 해서 셋팅해봤습니다.

개발환경

Eclipse Java EE IDE for Web Developers ( Eclipse IDE Neon 3 Packages x64 ) -> Spring Tool Suite 4 4.17.2.RELEASE

Spring 3.2.14.RELEASE -> 5.3.24

MyBastis 3.1.1 -> 3.5.11
Tomcat 7.x.x -> 9.0.71
JDK 1.7_x64 -> 11.0.18_x64
Maven 3.8.6 ( STS EMBEDDED )
PostgreSQL 14.1



pom.xml

<project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
 xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/maven-v4_0_0.xsd">
	<modelVersion>4.0.0</modelVersion>
	<groupId>test.study.spring</groupId>
	<artifactId>sample-spring-webapp</artifactId>
	<packaging>war</packaging>
	<version>0.0.1-SNAPSHOT</version>
	<name>sample-spring-webapp Maven Webapp</name>
	<url>http://maven.apache.org</url>
	<properties>
		<project.build.sourceEncoding>UTF-8</project.build.sourceEncoding>
		<org.springframework.version>5.3.24</org.springframework.version>
		<org.slf4j.version>2.0.6</org.slf4j.version>
		<org.codehaus.jackson.version>1.9.3</org.codehaus.jackson.version>

		<org.mybatis.version>3.5.11</org.mybatis.version>
		<org.mybatis.spring.version>2.1.0</org.mybatis.spring.version>
	</properties>
	<dependencies>
		<!-- Spring Framework -->
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-core</artifactId>
			<version>${org.springframework.version}</version>
		</dependency>
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-web</artifactId>
			<version>${org.springframework.version}</version>
		</dependency>
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-webmvc</artifactId>
			<version>${org.springframework.version}</version>
		</dependency>
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-jdbc</artifactId>
			<version>${org.springframework.version}</version>
		</dependency>
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-tx</artifactId>
			<version>${org.springframework.version}</version>
		</dependency>
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-context</artifactId>
			<version>${org.springframework.version}</version>
			<exclusions>
				<!-- Exclude Commons Logging in favor of SLF4j -->
				<exclusion>
					<groupId>commons-logging</groupId>
					<artifactId>commons-logging</artifactId>
				</exclusion>
			</exclusions>
		</dependency>
<!--
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-aop</artifactId>
			<version>${org.springframework.version}</version>
		</dependency>
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-beans</artifactId>
			<version>${org.springframework.version}</version>
		</dependency>
-->
<!--
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-context-support</artifactId>
			<version>${org.springframework.version}</version>
		</dependency>
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-expression</artifactId>
			<version>${org.springframework.version}</version>
		</dependency>
-->
		<dependency>
			<groupId>junit</groupId>
			<artifactId>junit</artifactId>
			<version>3.8.1</version>
			<scope>test</scope>
		</dependency>

		<dependency>
			<groupId>commons-beanutils</groupId>
			<artifactId>commons-beanutils</artifactId>
			<version>1.8.0</version>
		</dependency>
		<dependency>
			<groupId>commons-collections</groupId>
			<artifactId>commons-collections</artifactId>
			<version>3.2.1</version>
		</dependency>
		<dependency>
			<groupId>commons-digester</groupId>
			<artifactId>commons-digester</artifactId>
			<version>2.0</version>
		</dependency>
		<dependency>
			<groupId>commons-fileupload</groupId>
			<artifactId>commons-fileupload</artifactId>
			<version>1.2.2</version>
		</dependency>
		<dependency>
			<groupId>commons-lang</groupId>
			<artifactId>commons-lang</artifactId>
			<version>2.5</version>
		</dependency>
		<dependency>
			<groupId>commons-logging</groupId>
			<artifactId>commons-logging</artifactId>
			<version>1.1.1</version>
		</dependency>
<!--
		<dependency>
			<groupId>commons-dbcp</groupId>
			<artifactId>commons-dbcp</artifactId>
			<version>1.4</version>
		</dependency>
-->
		<dependency>
			<groupId>org.apache.commons</groupId>
			<artifactId>commons-dbcp2</artifactId>
			<version>2.9.0</version>
	    </dependency>
		<dependency>
			<groupId>commons-pool</groupId>
			<artifactId>commons-pool</artifactId>
			<version>1.5.4</version>
		</dependency>
		<dependency>
			<groupId>cglib</groupId>
			<artifactId>cglib</artifactId>
			<version>2.2.2</version>
		</dependency>

		<!-- https://mvnrepository.com/artifact/org.slf4j/slf4j-api -->
		<dependency>
		    <groupId>org.slf4j</groupId>
		    <artifactId>slf4j-api</artifactId>
		    <version>${org.slf4j.version}</version>
		</dependency>
		<dependency>
			<groupId>org.slf4j</groupId>
			<artifactId>jcl-over-slf4j</artifactId>
			<version>${org.slf4j.version}</version>
		</dependency>
		<!-- https://mvnrepository.com/artifact/ch.qos.logback/logback-classic -->
		<dependency>
		    <groupId>ch.qos.logback</groupId>
		    <artifactId>logback-classic</artifactId>
		    <version>1.4.7</version>
		    <scope>test</scope>
		</dependency>
<!--
		<dependency>
			<groupId>jdom</groupId>
			<artifactId>jdom</artifactId>
			<version>1.0</version>
		</dependency>

		<dependency>
			<groupId>joda-time</groupId>
			<artifactId>joda-time</artifactId>
			<version>2.0</version>
		</dependency>
-->
		<!-- JSON Dependency -->
		<!-- Java Object를 JSON으로 변환하거나 JSON을 Java Object로 변환하는데 사용하는 라이브러리 -->
		<!-- jackson-databind 라이브러리는 jackson-core 및 jackson-annotation 라이브러리의 의존성을 포함 -->
		<dependency>
		    <groupId>com.fasterxml.jackson.core</groupId>
		    <artifactId>jackson-databind</artifactId>
		    <version>2.9.10.5</version>
		</dependency>
<!--
		<dependency>
		    <groupId>net.sf.json-lib</groupId>
		    <artifactId>json-lib</artifactId>
		    <version>2.4</version>
		    <classifier>jdk15</classifier>
		</dependency>
		<dependency>
			<groupId>org.codehaus.jackson</groupId>
			<artifactId>jackson-mapper-asl</artifactId>
			<version>${org.codehaus.jackson.version}</version>
		</dependency>
-->

		<!-- postgresql -->
		<dependency>
			<groupId>org.postgresql</groupId>
			<artifactId>postgresql</artifactId>
			<version>42.2.25</version>
		</dependency>

		<!-- MyBatis Dependency -->
		<dependency>
			<groupId>org.mybatis</groupId>
			<artifactId>mybatis</artifactId>
			<version>${org.mybatis.version}</version>
		</dependency>
		<dependency>
			<groupId>org.mybatis</groupId>
			<artifactId>mybatis-spring</artifactId>
			<version>${org.mybatis.spring.version}</version>
		</dependency>

		<!-- Servlet Dependency -->
		<dependency>
			<groupId>javax.servlet</groupId>
			<artifactId>jstl</artifactId>
			<version>1.2</version>
		</dependency>
		<dependency>
			<groupId>javax.servlet.jsp</groupId>
			<artifactId>javax.servlet.jsp-api</artifactId>
			<version>2.3.3</version>
			<scope>provided</scope>
		</dependency>
		<dependency>
			<groupId>javax.servlet</groupId>
			<artifactId>javax.servlet-api</artifactId>
			<version>3.1.0</version>
			<scope>provided</scope>
		</dependency>
	</dependencies>
	<build>
		<finalName>sample-spring-webapp</finalName>
		<plugins>
			<plugin>
				<groupId>org.apache.maven.plugins</groupId>
				<artifactId>maven-war-plugin</artifactId>
				<version>3.2.1</version>
				<configuration>
					<warSourceDirectory>webapp</warSourceDirectory>
				</configuration>
			</plugin>
			<plugin>
				<groupId>org.apache.maven.plugins</groupId>
				<artifactId>maven-compiler-plugin</artifactId>
				<version>3.8.0</version>
				<configuration>
					<source>11</source>
					<target>11</target>
					<encoding>UTF-8</encoding>
				</configuration>
			</plugin>
			<plugin>
				<artifactId>maven-eclipse-plugin</artifactId>
				<version>1.9.3</version>
				<configuration>
					<downloadSources>true</downloadSources>
					<downloadJavadocs>true</downloadJavadocs>
					<wtpversion>2.0</wtpversion>
				</configuration>
			</plugin>
		</plugins>
	</build>
</project>



소스코드 : https://github.com/hermeswing/sample-spring-webapp



GitHub - hermeswing/sample-spring-webapp

Contribute to hermeswing/sample-spring-webapp development by creating an account on GitHub.

github.com

Log4j2  추가

Log4jdbc 추가

pom.xml

<project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
 xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/maven-v4_0_0.xsd">
	<modelVersion>4.0.0</modelVersion>
	<groupId>test.study.spring</groupId>
	<artifactId>sample-spring-webapp</artifactId>
	<packaging>war</packaging>
	<version>0.0.1-SNAPSHOT</version>
	<name>sample-spring-webapp Maven Webapp</name>
	<url>http://maven.apache.org</url>
	<properties>
		<project.build.sourceEncoding>UTF-8</project.build.sourceEncoding>
		<org.springframework.version>5.3.24</org.springframework.version>
		<org.slf4j.version>2.0.6</org.slf4j.version>
		<org.codehaus.jackson.version>1.9.3</org.codehaus.jackson.version>

		<org.mybatis.version>3.5.11</org.mybatis.version>
		<org.mybatis.spring.version>2.1.0</org.mybatis.spring.version>
	</properties>
	<dependencies>
		<!-- Spring Framework -->
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-core</artifactId>
			<version>${org.springframework.version}</version>
		</dependency>
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-web</artifactId>
			<version>${org.springframework.version}</version>
		</dependency>
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-webmvc</artifactId>
			<version>${org.springframework.version}</version>
		</dependency>
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-jdbc</artifactId>
			<version>${org.springframework.version}</version>
		</dependency>
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-tx</artifactId>
			<version>${org.springframework.version}</version>
		</dependency>
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-context</artifactId>
			<version>${org.springframework.version}</version>
			<exclusions>
				<!-- Exclude Commons Logging in favor of SLF4j -->
				<exclusion>
					<groupId>commons-logging</groupId>
					<artifactId>commons-logging</artifactId>
				</exclusion>
			</exclusions>
		</dependency>
<!--
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-aop</artifactId>
			<version>${org.springframework.version}</version>
		</dependency>
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-beans</artifactId>
			<version>${org.springframework.version}</version>
		</dependency>
-->
<!--
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-context-support</artifactId>
			<version>${org.springframework.version}</version>
		</dependency>
		<dependency>
			<groupId>org.springframework</groupId>
			<artifactId>spring-expression</artifactId>
			<version>${org.springframework.version}</version>
		</dependency>
-->
		<dependency>
			<groupId>junit</groupId>
			<artifactId>junit</artifactId>
			<version>3.8.1</version>
			<scope>test</scope>
		</dependency>

		<dependency>
			<groupId>commons-beanutils</groupId>
			<artifactId>commons-beanutils</artifactId>
			<version>1.8.0</version>
		</dependency>
		<dependency>
			<groupId>commons-collections</groupId>
			<artifactId>commons-collections</artifactId>
			<version>3.2.1</version>
		</dependency>
		<dependency>
			<groupId>commons-digester</groupId>
			<artifactId>commons-digester</artifactId>
			<version>2.0</version>
		</dependency>
		<dependency>
			<groupId>commons-fileupload</groupId>
			<artifactId>commons-fileupload</artifactId>
			<version>1.2.2</version>
		</dependency>
		<dependency>
			<groupId>commons-lang</groupId>
			<artifactId>commons-lang</artifactId>
			<version>2.5</version>
		</dependency>
		<dependency>
			<groupId>commons-logging</groupId>
			<artifactId>commons-logging</artifactId>
			<version>1.1.1</version>
		</dependency>
<!--
		<dependency>
			<groupId>commons-dbcp</groupId>
			<artifactId>commons-dbcp</artifactId>
			<version>1.4</version>
		</dependency>
-->
		<dependency>
			<groupId>org.apache.commons</groupId>
			<artifactId>commons-dbcp2</artifactId>
			<version>2.9.0</version>
	    </dependency>
		<dependency>
			<groupId>commons-pool</groupId>
			<artifactId>commons-pool</artifactId>
			<version>1.5.4</version>
		</dependency>
		<dependency>
			<groupId>cglib</groupId>
			<artifactId>cglib</artifactId>
			<version>2.2.2</version>
		</dependency>

		<dependency>
		    <groupId>org.bgee.log4jdbc-log4j2</groupId>
		    <artifactId>log4jdbc-log4j2-jdbc4.1</artifactId>
		    <version>1.16</version>
		</dependency>
		<!--
		* slf4j (slf4j 인터페이스와 log4j2를 연결해주는 모듈 역할)
        * 취약점 없는 최신버전으로 수정
        -->
    	<!-- https://mvnrepository.com/artifact/org.apache.logging.log4j/log4j-slf4j-impl -->
		<dependency>
			<groupId>org.apache.logging.log4j</groupId>
			<artifactId>log4j-slf4j-impl</artifactId>
			<version>2.17.2</version>
		</dependency>
		<dependency>
			<groupId>org.apache.logging.log4j</groupId>
			<artifactId>log4j-core</artifactId>
			<version>2.17.2</version>
		</dependency>
		<dependency>
			<groupId>org.apache.logging.log4j</groupId>
			<artifactId>log4j-api</artifactId>
			<version>2.17.2</version>
		</dependency>
<!--
		<dependency>
			<groupId>jdom</groupId>
			<artifactId>jdom</artifactId>
			<version>1.0</version>
		</dependency>

		<dependency>
			<groupId>joda-time</groupId>
			<artifactId>joda-time</artifactId>
			<version>2.0</version>
		</dependency>
-->
		<!-- JSON Dependency -->
		<!-- Java Object를 JSON으로 변환하거나 JSON을 Java Object로 변환하는데 사용하는 라이브러리 -->
		<!-- jackson-databind 라이브러리는 jackson-core 및 jackson-annotation 라이브러리의 의존성을 포함 -->
		<dependency>
		    <groupId>com.fasterxml.jackson.core</groupId>
		    <artifactId>jackson-databind</artifactId>
		    <version>2.9.10.5</version>
		</dependency>
		<!-- https://mvnrepository.com/artifact/p6spy/p6spy -->
		<dependency>
		    <groupId>p6spy</groupId>
		    <artifactId>p6spy</artifactId>
		    <version>3.9.1</version>
		</dependency>


		<!-- postgresql -->
		<dependency>
			<groupId>org.postgresql</groupId>
			<artifactId>postgresql</artifactId>
			<version>42.2.25</version>
		</dependency>

		<!-- MyBatis Dependency -->
		<dependency>
			<groupId>org.mybatis</groupId>
			<artifactId>mybatis</artifactId>
			<version>${org.mybatis.version}</version>
		</dependency>
		<dependency>
			<groupId>org.mybatis</groupId>
			<artifactId>mybatis-spring</artifactId>
			<version>${org.mybatis.spring.version}</version>
		</dependency>

		<!-- Servlet Dependency -->
		<dependency>
			<groupId>javax.servlet</groupId>
			<artifactId>jstl</artifactId>
			<version>1.2</version>
		</dependency>
		<dependency>
			<groupId>javax.servlet.jsp</groupId>
			<artifactId>javax.servlet.jsp-api</artifactId>
			<version>2.3.3</version>
			<scope>provided</scope>
		</dependency>
		<dependency>
			<groupId>javax.servlet</groupId>
			<artifactId>javax.servlet-api</artifactId>
			<version>3.1.0</version>
			<scope>provided</scope>
		</dependency>
	</dependencies>
	<build>
		<finalName>sample-spring-webapp</finalName>
		<plugins>
			<plugin>
				<groupId>org.apache.maven.plugins</groupId>
				<artifactId>maven-war-plugin</artifactId>
				<version>3.2.1</version>
				<configuration>
					<warSourceDirectory>webapp</warSourceDirectory>
				</configuration>
			</plugin>
			<plugin>
				<groupId>org.apache.maven.plugins</groupId>
				<artifactId>maven-compiler-plugin</artifactId>
				<version>3.8.0</version>
				<configuration>
					<source>11</source>
					<target>11</target>
					<encoding>UTF-8</encoding>
				</configuration>
			</plugin>
			<plugin>
				<artifactId>maven-eclipse-plugin</artifactId>
				<version>1.9.3</version>
				<configuration>
					<downloadSources>true</downloadSources>
					<downloadJavadocs>true</downloadJavadocs>
					<wtpversion>2.0</wtpversion>
				</configuration>
			</plugin>
		</plugins>
	</build>
</project>

context-datasource.xml

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
    xsi:schemaLocation="http://www.springframework.org/schema/beans https://www.springframework.org/schema/beans/spring-beans-4.0.xsd">

	<!-- 데이터베이스(커넥션풀) 등록 설정
	<bean id="dataSource" class="org.apache.commons.dbcp2.BasicDataSource" destroy-method="close">
		<property name="driverClassName" value="org.postgresql.Driver" />
		<property name="url" value="jdbc:postgresql://localhost:5432/springboot" />
		<property name="username" value="hermeswing" />
		<property name="password" value="pass" />
	</bean>
    -->
	<bean id="dataSource" class="org.apache.commons.dbcp2.BasicDataSource" destroy-method="close">
		<property name="driverClassName" value="net.sf.log4jdbc.sql.jdbcapi.DriverSpy" />
		<property name="url" value="jdbc:log4jdbc:postgresql://localhost:5432/springboot" />
		<property name="username" value="hermeswing" />
		<property name="password" value="pass" />
	</bean>
</beans>

log4jdbc.log4j2.properties

log4jdbc.dump.sql.maxlinelength = 0
log4jdbc.spylogdelegator.name   = net.sf.log4jdbc.log.slf4j.Slf4jSpyLogDelegator

log4j2.xml

<?xml version="1.0" encoding="UTF-8"?>
<Configuration status="ERROR">

	<Appenders>
		<Console name="console" target="SYSTEM_OUT">
			<PatternLayout
				pattern="%-5level %d{yy-MM-dd HH:mm:SSS}[%thread] %30logger[%method:%line] - %msg%n" />
		</Console>
	</Appenders>

	<loggers>
		<Root level="INFO" additivity="false">
			<AppenderRef ref="console" />
		</Root>

		<!-- log4j2 -->
		<logger name="log4jdbc.log4j2" level="error" additivity="false">
			<appender-ref ref="console" />
		</logger>

		<!-- QUERY LOG -->
		<!-- query + time -->
		<logger name="jdbc.sqltiming" additivity="false" level="INFO">
			<appender-ref ref="console" />
		</logger>
		<logger name="jdbc.sqlonly" level="off" />
<!--
		<logger name="jdbc.sqlonly" additivity="false" level="INFO">
			<appender-ref ref="console" />
		</logger>
		<logger name="jdbc.sqltiming" level="off" />
 -->
		<!-- RESULTSET TABLE -->
		<logger name="jdbc.resultsettable" additivity="false" level="INFO">
			<appender-ref ref="console" />
		</logger>


		<!-- 전체 로그 ( 양 상당히 많아짐 ) -->
		<logger name="jdbc.audit" level="off" />

		<!-- resultsettable + resultset (parameter) -->
		<logger name="jdbc.resultset" level="off" />

		<!-- connection log -->
		<logger name="jdbc.connection" level="off" />

		<logger name="com.console" level="INFO" additivity="false">
			<AppenderRef ref="console" />
		</logger>
	</loggers>
</Configuration>

소스코드 : https://github.com/hermeswing/sample-spring-webapp/tree/addOnLog4j2



GitHub - hermeswing/sample-spring-webapp

Contribute to hermeswing/sample-spring-webapp development by creating an account on GitHub.

github.com

Logback 특징

  • 빠른 implementation
  • 적은 메모리 공유
  • XML로 logging 설정
  • maxHistory 설정 값을 이용해 일정 기간이 지나면 로그파일 자동 삭제
  • Filter 기능 : 사용자별 level 조정 가능





https://hermeslog.tistory.com/643



[Log] DriverSpy 설정

개발환경 Spring boot 기반 net.sf.log4jdbc.sql.jdbcapi.DriverSpy context-datasource.xml application.yml ############################################################## # Server port server: servlet: context-path: / encoding: enabled: true charset: UTF-

hermeslog.tistory.com



728x90

'Spring Framework' 카테고리의 다른 글

[전자정부프레임워크] 샘플 프로젝트 생성 dev4.1  (0) 2023.06.27
[전자정부프레임워크] 전자정부프레임워크 설치  (0) 2023.06.22
[Spring] 개발환경 구축 - 이미지 파일 뷰  (0) 2023.01.20
[Spring] 개발환경 구축 - 대용량 Excel 다운로드  (0) 2023.01.19
[Spring] 개발환경 구축 - DBCP Connection Test  (0) 2022.12.29
'Spring Framework' Related Articles more
